Máy tính công nghiệp màn hình cảm ứng PPC-3181SW
Overview
18.5″ Fanless Panel PC with Intel® Core™ i5-6300U Processor
Features
- Industrial-grade 18.5″ LCD panel with 50k backlight lifetime
- True-flat touchscreen with multi-touch projected capacitive control
- High-performance, fanless 6th generation Intel® Core™ i processor
- Up to 16 GB DDR4 SDRAM
- Compact, fanless design with aluminum alloy enclosure
- IP65-rated front panel
- Supports dual displays (1 x external HDMI)
- Supports full-size mini PCIe expansion
- Supports USB 3.0
- Supports VESA 100

Chính sách bán hàng
- Bảo hành 24 tháng
- Miễn phí vận chuyển toàn quốc
- Miễn phí dịch vụ lắp đặt, tư vấn sử dụng tại Tp. Hồ Chí Minh
- Miễn phí dịch vụ bảo trì on-site trong vòng 1 năm tại Tp. Hồ Chí Minh (không bao gồm các huyện ngoại thành). Phản hồi trong vòng 24 tiếng kể từ khi nhận được thông báo.
- Dịch vụ lắp đặt, bảo trì on-site tại các tỉnh thành khác vui lòng liên hệ để được báo giá.
Specifications
System | CPU | 6th gen Intel® Core™ i5-6300U dual core (i7-6500U/i3-6100U optional) |
Frequency | 2.4 GHz; 3.0 GHz with turbo boost | |
L2 Cache | 3 MB | |
Memory | 1 x SODIMM DDR4 1866/2133 MHz (max. 16 GB) (1.2 V) | |
Storage | 1 x 2.5″ SATA bay 1 x mSATA bay | |
Network (LAN) | 2 x 10/100/1000 Mbps Ethernet (Intel I211-AT; Intel I219LM) | |
I/O | 2 x Serial ports: 1 x RS-232, 1 x RS-232/422/485(Adjustable through BIOS) 2 x USB 3.0, 2 x USB 2.0 1 x HDMI | |
Speaker | 2 x 1W | |
Expansion | 1 x Full-size mini PCIe slot | |
Watchdog Timer | 255 timer levels, set up by software | |
Physical Characteristics | Dimensions | 488 x 309 x 61.7 mm (19.2 x 12.1 x 2.4 in) |
Weight | 5.7 kg (12.56 lb) | |
OS Support | OS Support | Microsoft® Windows 7/8.1/10 (32/64-bit), WES7, Linux |
Power Consumption | Input Voltage | 12 ~ 24 VDC |
Power Consumption | 65W | |
LCD | Display Type | 18.5″ TFT LCD (LED backlight) |
Resolution | 1366 x 768 | |
Viewing Angle | 85 (left), 85 (right), 80 (up), 80 (down) | |
Luminance (cd/m2 ) | 450 Contrast Ratio 1000 | |
Backlight Lifetime | 50,000 hr | |
Touchscreen | Touch Type | 10-point multi-touch projected capacitive |
Light Transmission | 90 % ± 3 % | |
Controller | USB interface | |
Environment | Operating Temperature | 0 ~ 50 °C (32 ~ 122 °F) for SSD, 0 ~ 45 °C (32 ~ 113 °F) for HDD |
Storage Temperature | -20 ~ 60 °C (-4 ~ 140 °F) | |
Relative Humidity | 10 ~ 95% @ 40 °C (non-condensing) | |
Shock | Operating 10 G peak acceleration (11 ms duration), follow IEC 60068-2-27 | |
Vibration | Operating Random Vibration Test 5 ~ 500Hz, 1Grms @with HDD; 2Grms @with SSD, follow IEC 60068-2-64 | |
EMC | CE, FCC Class B, BSMI | |
Safety | CB, CCC, BSMI, UL | |
Front Panel Protection | IP65 compliant |
Máy tính công nghiệp màn hình cảm ứng PPC-3181SW
Downloads [PPC-3181SW]
