Ram công nghiệp Innodisk – DDR4 ECC UDIMM
Overview
DDR4 ECC UDIMM offers the industry’s fastest memory speed with 2666MT/s. The modules come equipped with 30μ” Gold Fingers and include single bit error correction. The modules are available in 4GB, 8GB, and 16GB capacities. 2133MT/s and 2400MT/s modules are also available.
ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use Hamming Code or Triple Modular Redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data.
Features
- Single Error Correction and Detection Available
- Fully Tested and Optimized for Stability and Performance
- Uses Original IC to Meet Strict Industrial Standards
- Anti-Sulfuration Protection Against Harsh Environments
- JEDEC Standard 1.2V (1.26V~1.14V)
- Operating Environment : 0°C ~ 85°C
- 30μ” Gold Finger
- RoHS Compliance
- CE/FCC Certification
Specifications
Interface | DDR4 |
Form Factor | ECC UDIMM |
Data Rate | 2133 MT/s, 2400 MT/s, 2666 MT/s |
Capacity | 4GB, 8GB, 16GB |
Function | ECC Unbuffered Memory |
Pin Number | 288pin |
Width | 72Bits |
Voltage | 1.2V |
PCB Height | 1.23 Inches |
Operating Temperature | 0°C to 85°C |
30μ” Gold Finger | Y |
Anti-Sulfuration | Y |
Order Information
Density | Component-Composition | Part Number | Rank | Voltage | Description |
4GB | 512Mx8 | M4C0-4GSSLCSJ | 1Rx8 | 1.2V | DDR4 2400 ECC UDIMM |
4GB | 512Mx8 | M4C0-4GSSLCIK | 1Rx8 | 1.2V | DDR4 2666 ECC UDIMM |
8GB | 512Mx8 | M4C0-8GSSMCSJ | 2Rx8 | 1.2V | DDR4 2400 ECC UDIMM |
8GB | 1Gx8 | M4C0-8GS1LCSJ | 1Rx8 | 1.2V | DDR4 2400 ECC UDIMM |
8GB | 512Mx8 | M4C0-8GSSMCIK | 2Rx8 | 1.2V | DDR4 2666 ECC UDIMM |
8GB | 1Gx8 | M4C0-8GS1LCIK | 1Rx8 | 1.2V | DDR4 2666 ECC UDIMM |
16GB | 1Gx8 | M4C0-AGS1MCSJ | 2Rx8 | 1.2V | DDR4 2400 ECC UDIMM |
16GB | 1Gx8 | M4C0-AGS1MCIK | 2Rx8 | 1.2V | DDR4 2666 ECC UDIMM |
Chính sách bán hàng
- Bảo hành 24 tháng
- Miễn phí vận chuyển toàn quốc
- Miễn phí dịch vụ lắp đặt, tư vấn sử dụng tại Tp. Hồ Chí Minh
- Miễn phí dịch vụ bảo trì on-site trong vòng 1 năm tại Tp. Hồ Chí Minh (không bao gồm các huyện ngoại thành). Phản hồi trong vòng 24 tiếng kể từ khi nhận được thông báo.
- Dịch vụ lắp đặt, bảo trì on-site tại các tỉnh thành khác vui lòng liên hệ để được báo giá.
