Ram công nghiệp Innodisk – DDR4 SODIMM VLP
Overview
DDR4 SODIMM VLP offers a compact and very low-profile design and the industry’s fastest memory speed with 2666MT/s, and it is fully compatible with the Intel® Purely platform and 1U devices. The modules comply with all relevant JEDEC standards and are available in 4GB and 8GB capacities. 2400MT/s module is also available.
VLP modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact.
Features
- Small Outline Dual In-line Memory Module
- Single Error Correction and Detection Available
- Fully Tested and Optimized for Stability and Performance
- Uses Original IC to Meet Strict Industrial Standards
- Anti-Sulfuration Protection Against Harsh Environments
- JEDEC Standard 1.2V (1.26V~1.14V)
- Operating Environment : 0°C ~ 85°C
- 30μ” Gold Finger
- RoHS Compliance
- CE/FCC Certification
Specifications
| Interface | DDR4 |
| Form Factor | SODIMM VLP |
| Data Rate | 2400 MT/s, 2666 MT/s |
| Capacity | 4GB, 8GB |
| Function | Non-ECC Unbuffered Memory |
| Pin Number | 260pin |
| Width | 64Bits |
| Voltage | 1.2V |
| PCB Height | 0.7 Inches |
| Operating Temperature | 0°C to 85°C |
| Anti-Sulfuration | Y |
Order Information
| Density | Component Composition |
Part Number | Rank | Voltage | Description |
| 4GB | 512Mx8 | M4S0-4GSS3CSJ | 1Rx8 | 1.2V | DDR4 2400 SODIMM VLP |
| 4GB | 512Mx8 | M4S0-4GSS3CIK | 1Rx8 | 1.2V | DDR4 2666 SODIMM VLP |
| 8GB | 1Gx8 | M4S0-8GS13CSJ | 1Rx8 | 1.2V | DDR4 2400 SODIMM VLP |
| 8GB | 1Gx8 | M4S0-8GS13CIK | 1Rx8 | 1.2V | DDR4 2666 SODIMM VLP |
