Máy tính công nghiệp không quạt P2002E
Overview
6th Generation Intel® Core™ U Series (Skylake) Expandable Fanless Computer with CFM and CDS Interface
Features
- Onboard Intel® 6th Generation Core™ U Series Processor (15W)
- 2x DDR4 SO-DIMM Socket, Support Up to 32 GB
- Advanced Graphics Engine Support Triple Independent Display
- 2x 2.5” SATA HDD Bay, 1x mSATA and 1x CFast Socket
- 2x Full Size Mini-PCIe Socket
- 1x PCI or 1x PCIex4 Expansion slot
- Support CFM (Control Function Module) Technology
- Support 2x PoE+, Individual Port Offers Max. 25.5W (with optional CFM module)
- Support Ignition Sensing Function (IGN) (with optional CFM module)
- Rich I/O (2x GbE LAN, 6x COM, 5x USB, 16x Isolated DIO)
- Support Instant Reboot Technology
- Support CDS Technology for Convertible Panel PC
- Wide Operating Temperature (-25°C to 70°C)
- SuperCap integrated for Battery Maintenance-Free
Specifications [P2002E]
| Model Name | P2002E |
| Processor System | Onboard 6th Intel® Core™ U processors (Skylake) – Intel® Core™ i5-6300U processor (3M Cache, up to 3.00 GHz) – Intel® Core™ i3-6100U processor (3M Cache, 2.30 GHz) – TDP: 15 W – BIOS: AMI 64Mbit SPI BIOS |
| Memory | 2x DDR4 260-pin SO-DIMM socket, support up to 32 GB (2133MHz, un-buffered and non-ECC type) |
| Graphics | Intel® HD Graphics 520 |
| Triple independent display with 1x VGA, 1x DVI-D and 1x CDS interface | |
| Audio | Realtek® ALC888-GR |
| High Definition Audio | |
| I/O Interface | 1x VGA (Up to 1920 x 1080 @ 60Hz), DB-15 |
| 1x DVI-D (Up to 1920 x 1080 @ 60Hz) | |
| 1x CDS Interface, Compact PCI Connector | |
| 2x GbE LAN (Support WoL, Teaming, Jumbo Frame and PXE), RJ45 – GbE1: Intel I219LM – GbE2: Intel I210AT |
|
| 2x PoE+ (with Optional CFM PoE Module) – Comply with IEEE 802.3at, Offers Up to 25.5W Per Port |
|
| 6x RS-232/422/485 with Auto Flow Control (Support 5V/12V), DB9 | |
| 4x USB 3.0, Type-A | |
| 1x USB 2.0, Type-A | |
| 16x Isolated DIO (8x DI/8x DO), 20-Pin Terminal Block | |
| 1x Line-out & 1x Mic-in, Phone Jack 3.5mm | |
| 1x Power On/Off Switch | |
| 1x Reset Button | |
| 1x AT/ATX Switch | |
| 1x Remote Power On/Off Connector, 2-Pin Terminal Block | |
| 1x External FAN Connector, 4-Pin Terminal Block | |
| Storage | 2x 2.5” SATA HDD/SSD Bay, Support RAID 0/1 (Gen3) |
| 2x mSATA (One Shared by Mini-PCIe Socket) (Gen2) | |
| 1x CFast Socket (Gen3) | |
| Expansion | 1x CFM PoE interface |
| 1x CFM IGN interface | |
| 2x Full-size Mini-PCIe Socket | |
| 1x PCI or 1x PCIex4 Expansion slot Optional Riser Card: 1x PCI, 1x PCIex4 Support maximum dimension of add-on card (H x L): 100mm x 200mm |
|
| 1x Universal I/O Bracket | |
| 1x SIM Socket | |
| 4x Antenna Hole | |
| Other Function | Support CDS Technology |
| Support CFM Technology | |
| Support Instant Reboot Technology (0.2 sec) | |
| Support Power Ignition Sensing (IGN) | |
| Support OSD Function (LCD On/Off, Brightness Up, Brightness Down for CDS Display Module) |
|
| Internal Speaker AMP 2W + 2W | |
| SuperCap Integrated | |
| Watchdog Timer: Software Programmable Supports 1~255 sec. System Reset |
|
| Power Requirement | Support AT/ATX Power Mode |
| Power Input Voltage 9~48VDC | |
| One 3-pin Terminal Block Connector | |
| Optional Power Adapter AC/DC 12V/5A 60W or 24V/5A 120W | |
| Physical | Dimension (WxDxH): 254.5 x 220 x 72 mm |
| Weight: 3.18 kg | |
| Extruded Aluminum with Heavy Duty Metal | |
| Support Wall / VESA / CDS Mounting | |
| Fanless Design | |
| Jumper-less Design | |
| Protection | Reverse Power Input Protection |
| Over Voltage Protection: 58V | |
| Over Current Protection: 15A | |
| ESD Protection: +/-15kV (air), +/-8kV (contact) | |
| Surge Protection: 3kW | |
| Operating Stystem | Windows® 10 Windows® 8.1 Windows® 7 |
| Linux® Kernel 4.4 | |
| Environment | Operating Temperature: -25°C to 70°C (With extended temperature peripherals; Ambient with air flow According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14) |
| Storage Temperature: -40°C to 85°C | |
| Relative Humidity: 95% RH @ 40°C (Non-condensing) | |
| Shock: Operating, 50 Grms, Half-sine 11 ms Duration (with SSD, according to IEC60068-2-27) |
|
| Vibration: Operating, 5 Grms, 5-500 Hz, 3 Axes (with SSD, according to IEC60068-2-64) |
|
| EMC: CE, FCC Class A |
